Specifications - Density meter Excellence D4
| Accuracy ± (g/cm³) |
0.0001 g/cm3 |
| Repeatability (g/cm³) |
0.00005 g/cm3 |
| Resolution (g/cm³) |
0.0001 g/cm3 |
| Temperature Control Range |
0 °C – 95 °C |
| Measurement Scales |
Density, Specific gravity, Alcohol, Acid, API, Sugar, Urea, User-defined concentration Up to 30 user-defined concentration tables (can be entered as tables or formulas). |
| Weight |
17.5 kg |
| Connectivity |
3 × USB host (printer, memory stick, barcode reader, hub, keyboard, mouse) CAN (Multiple LevelSens) Ethernet (Network and PC Software) HDMI (Terminal) RS232 (Automation units) USB client (PC Software) |
| Minimum sample volume |
1.50 mL (1.5 mL) |
| Built-in Measurement Scales |
Acids / bases and chemical tables Alcohol tables Brix / Sugar tables Density / Specific gravity User programmable tables / functions |
| Product Type |
Benchtop Density Meter |
| Display / User interface |
7" display with color touchscreen |
| PC Software |
LabX Express and Server |
| Clean check |
Yes |
| Automatic bubble detection (BubbleCheck™) |
Yes |
| Languages |
Chinese English French German Italian Polish Portuguese Russian Spanish |
| Automatic viscosity correction |
Yes |
| Note: |
Accuracy valid under ideal conditions and for samples with low densities and viscosities |
| Standard compliance |
www.mt.com/dere-norms |
| Integrated drying pump |
No |
| User Management |
Yes |
| Measurement range (g/cm³) |
0 g/cm3 – 3 g/cm3 |
| LIMS connectivity |
Yes |
| Video view |
Yes |
| Norms and Standards |
ANSI 1250 AOAC Official Method 988.06 API Std 2540 ASTM D 1250 ASTM D 1475 ASTM D 2501 ASTM D 4052 ASTM D 4806 ASTM D 5002 ASTM D 6448 ASTM D5931 Chinese pharmacopoeia 0601 DIN 51757 DIN EN ISO 3675 EN 14214:2003 GB/T 13531.4-2013 GB/T 2013-2010 GB5009.225—2016 GBT 11540-2008 IP 200/52 IP 365 ISO 12185-2 ISO 18301 ISO 2811-3 ISO 91 ISO/EN 15212-1 JJF1070-2005 OIV Analysis method for density measurement in wine and musts OIV MA-BS-03 and/or MA-BS-03 Ph. Eur. 2.2.5 Pharm. Eu. (2005) JP (2005) USP (2006) USP chapter 841 (as of USP 29) |
| Automatic sample detection |
Yes |
| Automation for Enhanced Workflow |
Autosampler (up to 303 samples) Multiparameter (refractive index, color, pH, etc) Sampling and cleaning (1 sample) |
| Dimensions (Width x Height x Depth) |
267 x 226 x 256 mm |
| Integrated pressure sensor |
Yes |
| Compliance / Data Security |
21 CFR part 11 / EU Annex 11 (requires LabX software) Audit Trail (requires LabX software) Data integrity (requires LabX software) |
| Color-coded result identification |
Yes |
| Temperature control |
Yes |
| On-screen help texts |
Yes |
| Barcode reader connectivity |
Yes |
| Product Line |
Excellence |
