Multi-Channel Water Controller
EL300
The EL300 is a universal water controller based on a modular concept.
The EL300 can adapt to many different probes and configurations, mono or multi-channel. It allows the connection of one or several probes for each parameter among pH, ORP, dissolved oxygen, conductivity, chlorine, total suspended solid (TSS), total dissolved solid (TDS), temperature and turbidity in the limit of 16 channels. A very user-friendly interface can display all the values as well as graphs of the recorded values with periods from 10 minutes to one month. A USB port allows to transfer the recorded measurements that may be imported to Excel for treatments or graphs. A new web-based interface allows the control and the troubleshooting at distance using an internet browser on a computer, tablet or iPhone.
Multi-channel water controller, EL300 - Parameter specification
| Parameter | Standard Range Other ranges on request | Typical Repeatability | Accuracy (On Standard Solution) |
|---|---|---|---|
| pH | 0-14 | +/- 0.01 pH | +/- 2% |
| ORP | +/-2000 mV | +/- 1 mV | +/- 2% |
| Dissolved oxygen | 0-25 mg/l O2 | +/- 0.02 mg/l O2 | +/- 2% |
| Conductivity | 0-20 μS (K=0.01) 0-200 μS (K=0.1) 0-2000 μS (K=1) 0-20 mS (K=10) |
+/- 0.01 μS +/- 0.1 μS +/- 1 μS +/- 0.01 mS |
+/- 2% +/- 2% +/- 2% +/- 2% |
| Total Residual Chlorine | 0-5 mg/l | +/- 0.01 mg/l | +/- 2% |
| pH | 0-14 | +/- 0.01 pH | +/- 2% |
| Turbidity (TSS by correlation) |
0-4 NTU 0-40 NTU 0-400 NTU |
+/- 2% +/- 2% +/- 2% |
|
| TSS (Total Suspended Solid) | 0-1500 mg/l TSS 0-30000 mg/l TSS |
+/- 1% of reading or +/- 2 mg/l TSS +/- 1% of reading or +/- 2 mg/l TSS |
+/- 2% +/- 2% |
| TDS (Total Dissolved Solid) | 0 – 20 mg/l 0 – 200 mg/l 0 – 2000 mg/l 0 – 20 g/l |
+/- 0.01 mg/l +/- 0.1 mg/l +/- 1 mg/l +/- 0.01 g/l |
+/- 2% +/- 2% +/- 2% +/- 2% |
| Temperature | 0-80°C | +/- 0.1 °C | +/- 2% +/- 2% |
