HACH Orbisphere K1100 LDO Sensor Kit, 0-2000 ppb, 410 controller, 6 mm flow chamber, panel mount PN.K1100-KTO-P-MET
HACH Orbisphere K1100 LDO Sensor Kit, 0-2000 ppb, 410 controller, 6 mm flow chamber, panel mount PN.K1100-KTO-P-MET
无法加载取货服务可用情况
* Please consult before ordering
The first maintenance-free optical oxygen sensor for power plants.
Pre-configured Kit containing high accuracy Luminescent Dissolved Oxygen sensor K1100-S00, controller 410K/P1C00000, 3 m cable, 6 mm flow chamber. Specially designed for power plants (non-nuclear).
The Orbisphere K1100 optical sensor together with the Orbisphere controller offers a new way of monitoring oxygen in power plants. Orbisphere sensors set the industry standards for oxygen measurement by offering peace of mind to every water chemist.
Benefits
One calibration per year
One zero point calibration per year is all that is needed with the K1100 sensor. Designed for minimal drift, luminescent technology makes the K1100 sensor the most stable sensor with the longest calibration interval in the industry.
No membranes = two minutes of maintenance
With no membranes to replace and no electrolyte solution to replenish, the K1100 requires only two minutes of maintenance per year. Corrosive or hazardous chemicals are not required, making the annual task faster, easier and safer without reducing measurement precision.
Low cost retrofit
The complete system consists of a controller, a flow chamber, and the K1100 Luminescent Dissolved Oxygen Sensor. The sensor is compatible with Hach Orbisphere 28 mm flow chambers, eliminating the need for engineering changes. Installation is fast and easy and does not require special preparation.
A new level of confidence
The K1100 optical sensor is the first to use luminescent measurement technology to measure both ppb and ppm oxygen levels in power plants. Since 1978, Hach Orbisphere sensors have set the industry standard for oxygen measurement by delivering confidence to every water chemistry manager. The K1100 maintains this tradition and offers significant operating and cost benefits.
Specifications
Technical Attributes
| Accuracy | ± 0.8 ppb or 2 % whichever is greater |
| Ambient Temperature | -5 - 50 °C (23 - 122°F) |
| Analog Outputs | 3 Smart 0/4 to 20 mA (500 Ohms) programmable as linear or tri-linear, configurable to send diagnostics or alarm informations. |
| Application | Power |
| Calibration | Single point zero calibration |
| Certifications | 2004/108/EC - EN 61326-1 |
| Communication Capabilities | 3 x 0/4-20 mA; RS485; Ethernet |
| Controller | Panel |
| Controller Options | 410 Mono-Channel Controller |
| Display Resolution | 0.1 ppb |
| Lower Limit of Detection (LOD) | 0.6 ppb |
| Mounting | 6 mm flow chamber |
| Parameter | Oxygen |
| Power Requirements (Voltage) | 100 - 230 VAC |
| Range | 0 - 2000 ppb dissolved O₂ (DO) |
| Relays | Measurement board: 3 measurement alarm relays (1A-30 VAC or 0.5A-50 VDC), configurable to send diagnostics information. Main board: 1 system alarm relay (1A-30 VAC or 0.5A-50 VDC). |
| Repeatability | ± 0.4 ppb or 1 % whichever is greater |
| Reproducibility | ± 0.8 ppb or 2 % whichever is greater |
| Response Time | (90%) <10 s (gas phase); <30 s (liquid phase) |
| Sample Flow Rate | 50 - 300 mL/min |
| Sample Pressure | 1 - 20 bar absolute (14.5 - 290 psi) |
| Sample Temperature | -5 - 50°C (23 - 122°F) |
| Sensors | K1100 LDO |
| Storage Conditions | -5 °C - 100 °C |
| Temperature Range | Accurate from -5 - 50 °C (23 - 122 °F) Resistant - temperature from -5 - 100 °C (23 - 212 °F) |
| Warranty | 12 months |
| Weight Sensor | 0.6 |
| What's included? | Includes 410 panel mount controller, K1100 LDO sensor (low level), 3 m sensor cable, stainless steel flow-chamber with 6 mm fittings |
