ChemTron

ChemTron VDM-300 heat benchtop density/viscosity meter

ChemTron VDM-300 heat benchtop density/viscosity meter

常规价格 $99,999.00 USD
常规价格 促销价 $99,999.00 USD
促销 售罄

* Please Contact Us for the Best Quote and to Confirm Delivery Time

VDM-300 heat benchtop density/viscosity meter

Density range: 3 0.5~3 g/cm3, density accuracy: 3 3 3 ±0.0002 g/cm3, ±0.0005 g/cm3, ±0.001 g/cm3, temperature range: up to +100℃ (+212OF)

VDM-300 heat benchtop density/viscosity meter

Integrated measurement of density, kinematic viscosity and temperature
* Suitable for transformer oil, hydraulic oil, lubricating oil, crude oil, fuel oil, diesel oil, engine oil, food and beverage, etc., in line with ASTM D445, ISO 3 104, IP71 method.
* VDM-300 heat can meet the test requirements of measuring density and kinematic viscosity at the same time
* Use the principle of sensitive elements to generate different frequencies for samples of different densities
* Can quickly measure the density value and dynamic viscosity value, and then calculate the motion of the sample Viscosity
* Over-range amperometric monitoring design to prevent damage to the measurement system
* Can be connected to computers and printers via Bluetooth

Technical Parameters

Dynamic viscosity range

0.2~2000mPa.s(0.2~2000cP)

Kinematic Viscosity Accuracy

±1% (measured value)

Density range

3 0.5~3 g/cm3

Density accuracy

3 3 3 ±0.0002 g/cm3 , ±0.0005 g/cm3 , ±0.001 g/cm3

temperature range

Up to +100°C (+212OF)

Probe Material

316L Stainless Steel, Nickel Base Alloy, Hastelloy C22

data transmission

Can connect computer and printer via bluetooth

Viscosity effect

automatic compensation

CE mark

Comply with EN 61326; EN5011; EN50082-2

external dimensions

140×100×290mm

weight

about 2kg
