ChemTron OHS.6 Remotely Controllable High Torque / High Speed Stirrer
ChemTron OHS.6 Remotely Controllable High Torque / High Speed Stirrer
无法加载取货服务可用情况
*Please Contact Us for the Best Quote and to Confirm Delivery Time
Remotely Controllable High Torque / High Speed Stirrer
Speed range: 20-800rpm; Control accuracy: ±1rpm
Remotely Controllable High Torque / High Speed Stirrer
> Suitable for reaction systems and other high torque / high speed applications
> Set speed can be maintained when viscosity of liquid changes
> Brushless DC motor made in Germany, for high performance stirring processes
> Maintenance-free
> Quiet and reliable
> Digitally adjustable rotation speed and direction
> Remote controller can display actual speed and actual torque as well as the set speed
> Digital (RS-232/485) and analog communication available for remote PC or PLC contro
Features
> Vibration-free and silent operation.
> Powerful torque capable of handling high viscosity tasks.
> Maintenance of constant motor speed by control system even under conditions of changing viscosity.
> Best effort function intelligently manages its stirring speed to keep stirring even if the workload is out of its capacity.
> Prevention of accidental spills or splashes thanks to microprocessor-controlled smooth start and stop functions.
Technical parameters
| type | OHS.6 |
| Display control method | LCD digital display speed and torque / digital control |
| Speed range (rpm) | 20-800 |
| Control accuracy (rpm) | ±1 |
| stirring viscosity (cps) | 150000 |
| Torque(Ncm) | 1320 |
| Continuous Rated Torque (Ncm) | 188 |
| Stirring volume (L) H2O | 50 |
| Input/Output Power(W) | 150 |
| Motor size(mm) | 216×65×65 |
| Motor weight(Kg) | 2.3 |
